Dynacord CMS 1600-3 mixer

  • Has 16 microphone inputs
  • Has parametric and graphic equalizer
  • It has two line effects
  • Number of MON outputs: 2
  • Number of AUX outputs: 2
Manufacturer: Dynacord brand
Call for pricing
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Introducing the Dynacord CMS 1600-3 mixer

This Dynacord mixer model has 16 input lines. This means you can connect 16 microphones to this mixer as standard.
In general, the base and design of Dynacord mixers are fixed, and the only thing that changes in the company's mixers is the number of mixer inputs. To find out if a Dynacord mixer has multiple mic inputs, simply delete the last two zeros of the mixer model.
For example, the Dynacord CMS 1600-3 mixer has 16 microphone inputs and the Dynacord CMS 600-3 mixer has 6 microphone inputs. In addition to the number of microphone inputs, the number of AUX and MON outputs may vary according to the different Dynacord mixer models.
It also has two digital effects made up of two completely separate circuits, each of which has 100 predefined effect templates and of course can be edited.
This device also gives you the ability to program 20 effect patterns separately on the device.
This device has an 11-band stereo equalizer and four inputs via a USB connector.
My personal opinion is that this device is not very different from the Dynacord CMS 1000-3 mixer and differs only in the number of input lines (Line).
Of course I must also say that the 6 extra lines can be very useful in heavy and professional work.

Other Details

  • Intuitive mixer with 16 input channels (12 Mic/Line + 4 Mic/Stereo-Line)
  • 2 High-Quality editable effects, 100 factory and 20 user presets
  • Professional 4×4 24-bit / 96 kHz USB interface with MIDI
  • 11 band stereo graphic equalizer
  • Optional robust cover-lid with integrated handle

The Compact Mixing System from DYNACORD has seized pole position in this segment of the market by virtue of the quality of its sound, components and features. By integrating a high-quality mixer, two digital effects processors of studio grade, a graphic equalizer and also a professional digital interface to PC or Mac, the CMS mixers represent the ideal solution for a large number of demanding applications in the audio sector.

The mixing section starts with 16 lowest noise, discrete microphone preamps. 6 auxiliary busses, two of them switchable pre/post fader, allow high flexibility for monitoring. The two effects processors offer 100 factory presets, including the already legendary PowerMate-reverbs. A TAP key allows precise setting of delay times. Further, each preset can be edited and stored to 20 User memories.

The built in uncompromising USB audio interface shares 4 playback and 4 recording channels simultaneously with a PC or Mac, following studio standard 24-bit / 96 kHz. An additional MIDI interface allows integration of instruments, such as keyboards. A license for Steinbergs Cubase software is part of the package.

The 11 band stereo graphic equalizer can be routed flexible to master or monitor channels.

For dark environments an optional gooseneck light can be connected. All faders are dust protected and not least the balanced XLR outputs for master and monitor underline the professional approach.

Optional a very robust cover lid with an integrated handle is available. A solution that offers optimal protection for the device as well as greater carrying comfort without the need of adding a large, heavy flight case.
