Dynacord PowerMate 600-3 Power Mixer Specifications
This Dynacord power mixer model has six balanced mic line inputs and two unbalanced stereo input lines.
The effect used in this template consists of two completely separate circuits, each of which has 100 stored effect templates and of course can be edited, so that the user can save up to 20 hand effect templates with the desired name.
The output power of this model is 1000 real watts (RMS) with a unique impedance of 4 ohms. The difference between this mixer and the CMS 600-3 is that it has the same amplifier.
In this power mixer, the recorder can use two outputs, MONO and AUX, for active speakers.
The point I have to make here is that the weight of this device is very low compared to its capabilities.
The weight of this device is approximately 9 kg (Kg), which makes this device very easy to carry.
8‑channel compact power‑mixer
- Mixer with 8 input channels (4 Mic/Line + 2 Mic/Stereo-USB + 2 Stereo-Line)
- Very powerful and reliable amplifier with 2 x 1.000 Watts / 4 Ohms
- 2 High-Quality editable effects, 100 factory and 20 user presets
- Professional 4×4 24-bit / 96 kHz USB interface with MIDI
- Lightweight (9.5 kg) road-ready package with extra robust cover-lid
The PowerMate compact power mixers incorporate profound know-how, based on our research, development and inter-communication with our customers in the professional audio market, for decades.
It incorporates not less than six dedicated audio devices into one compact frame: mixing console, two effects units, graphic equalizer, USB audio interface and power amplifier. Each of them is on the highest quality level as you would expect from a stand-alone device. The PowerMate is a real all-rounder for almost all applications with maximum feature set at minimum size.
The mixing section starts with 6 lowest noise, discrete microphone preamps. 3 auxiliary busses, one of them switchable pre/post fader, allow high flexibility for monitoring. The two effects processors offer 100 factory presets, including the already legendary PowerMate-reverbs. Further, each preset can be edited and stored to 20 User memories.
The built in USB audio interface shares 4 playback and 4 recording channels simultaneously with a PC or Mac, following studio standard 24-bit / 96 kHz. An additional MIDI interface allows integration of instruments, such as keyboards. A license for Steinbergs Cubase software is part of the package.
The 9 band stereo graphic equalizer allows precise tone control for speakers and room matching.
The amplifier is extremely powerful with 2 x 1000 W / 4 Ohms (RMS). Due to modern switching mode power supply technology and a class-D output stage, it’s very efficient and lightweight, too. An optional speaker protection allows limitation of long-term power without giving up dynamics.
Finally, the slim housing is protected by a rugged plastic lid, hold by strong snap in magnets.
